Specification of Off-grid Pure Sine Wave Power Inverters
|
||||
|
Model
|
Description
|
|||
|
Input |
DC Voltage
|
12V or 24V or 48V or 72V or 110V
|
||
|
Voltage Range
|
10-15VDC or 21-30VDC or 42-60VDC or 62-85VDC or 90-135VDC
|
|||
|
No Load Current Draw
|
< 1.9A
|
|||
|
Efficiency
|
> 85%
|
|||
|
Output |
AC Voltage
|
100/110/120VAC or 220/230/240 VAC
|
||
|
Rated Power
|
6000w Continuous Power
|
|||
|
Surge Power
|
12000w
|
|||
|
Waveform
|
Pure Sine Wave
|
|||
|
Frequency
|
50Hz or 60Hz
|
|||
|
AC Regulation
|
3%
|
|||
|
Protection |
Low Voltage Alarm
|
10DC±0.5V or 20.5DC±1V or 44VDC±1V or 64VDC±1V or 92VDC±1V
|
||
|
Low Voltage Shut Down
|
9.5DC±0.5V or 19.5DC±1V or 42VDC±1V or 62VDC±1V or 90VDC±1V
|
|||
|
Over Load
|
Shut Off Output
|
|||
|
Over Voltage Shut Down
|
15.5V or 30.5V or 61.2V or 85V or 135V
|
|||
|
Over Thermal
|
Shut Off Output Automatically
|
|||
|
Fuses
|
Short Circuit
|
|||
|
Environment |
Working Temperature
|
Between -10℃ and +50℃
|
||
|
Working Humidity
|
20%～90%RH
|
|||
|
Storage Temperature
|
Between -30℃ and +70℃
|
|||
|
Others |
Start
|
Soft Start
|
||
|
Cooling Ways
|
Cooling Fan
|
|||
|
Total Harmonic Distortion
|
THD < 5%
|
|||
1. Pure Sine Wave, as good as the grid power.
2. Full Power.
3. Core Technology, German Design.
4. Most Advanced Program in Software.
5. Complete Protection Non Defect Rate.
6. Better EMC – Electro Magnetic Compatibility.
7. No Noise for TV or Stereo Sound.
8. SMT- Surface Mounting Technology.
9. All Big Imported Mosfet,Strong Driving Capacity.
10. PCB Thickness :2.00m
11. LED Display.
12. Compact Design, Less Weight, Full Power.
13. Single Layer Design, Easy to Repair if any.
14. Earth Connection for Both Inverter and PCB.
15. Low No Load Current Draw.
16. Durable quality with 10 years usage,
17. Alarm and LED Indication Light for error warning.New inevrter with LED display, let you monitor the inverter input voltage and output voltage in time. With this function, you will know about the inverter condition more clearly.
18. Sufficient Heat Radiation
19. More Vent Holes on the plates and the bottom for heat radiation
20. Popular Metal Black Design
21. Big Current Connector,
22. All kinds of socket are available
23. Strong Wiring Row on AC End.
24. Best quality ever in the market.
25. Factory Price.
Build Your Cozy Zone in Vehicles
everywhere.Build your zone cozy and efficiency.
Enjoy Your Leisure Nature Time
leisure nature time.
