Pure sine wave inverter 300W 500W 1000W 1500W 2000W 3000W 4000W 5000W 6000W Inverter With Intelligent LCD Display
Model:CRD-300W
Output Waveform:pure sine wave
Rated Power: 300W
Peak Power: 600W
Output voltage: AC100/110/120/220/230/240
Input voltage:DC12/24/48/60/90/110
Frequency:60HZ/50HZ
Size：150*104*70mm
N.W. :0.65KGS
Rated Power: 300W
Peak Power: 600W
Output voltage: AC100/110/120/220/230/240
Input voltage:DC12/24/48/60/90/110
Frequency:60HZ/50HZ
Size：150*104*70mm
N.W. :0.65KGS
Model:CRD-500W
Output Waveform:pure sine wave
Rated Power: 500W
Peak Power: 1000W
Output voltage: AC100/110/120/220/230/240
Input voltage:DC12/24/48/60/90/110
Frequency:60HZ/50HZ
Size：211*104*70mm
N.W. :0.95KGS.
Rated Power: 500W
Peak Power: 1000W
Output voltage: AC100/110/120/220/230/240
Input voltage:DC12/24/48/60/90/110
Frequency:60HZ/50HZ
Size：211*104*70mm
N.W. :0.95KGS.
Model:CRD-1000W
Output Waveform:pure sine wave
Rated Power: 1000W
Peak Power: 2000W
Output voltage: AC100/110/120/220/230/240
Input voltage:DC12/24/48/60/90/110
Frequency:60HZ/50HZ
Size：230*153*70mm
Rated Power: 1000W
Peak Power: 2000W
Output voltage: AC100/110/120/220/230/240
Input voltage:DC12/24/48/60/90/110
Frequency:60HZ/50HZ
Size：230*153*70mm
N.W.:1.95KGS.
Model:CRD-1500W
Output Waveform:pure sine wave
Rated Power: 1500W
Peak Power: 3000W
Output voltage: AC100/110/120/220/230/240
Input voltage:DC12/24/48/60/90/110
Frequency:60HZ/50HZ
Size：280*153*70mm
N.W. :2.4KGS
Rated Power: 1500W
Peak Power: 3000W
Output voltage: AC100/110/120/220/230/240
Input voltage:DC12/24/48/60/90/110
Frequency:60HZ/50HZ
Size：280*153*70mm
N.W. :2.4KGS
Model:CRD-2000W
Output Waveform:pure sine wave
Rated Power: 2000W
Peak Power: 4000W
Output voltage: AC100/110/120/220/230/240
Input voltage:DC12/24/48/60/90/110
Frequency:60HZ/50HZ
Size：350*153*70mm
N.W.:3.0KGS
Rated Power: 2000W
Peak Power: 4000W
Output voltage: AC100/110/120/220/230/240
Input voltage:DC12/24/48/60/90/110
Frequency:60HZ/50HZ
Size：350*153*70mm
N.W.:3.0KGS
Model:CRD-3000W
Output Waveform:pure sine wave
Rated Power: 3000W
Peak Power: 6000W
Output voltage: AC100/110/120/220/230/240
Input voltage:DC12/24/48/60/90/110
Frequency:60HZ/50HZ
Size:410*165*70mm
N.W.:4.7KGS
Rated Power: 3000W
Peak Power: 6000W
Output voltage: AC100/110/120/220/230/240
Input voltage:DC12/24/48/60/90/110
Frequency:60HZ/50HZ
Size:410*165*70mm
N.W.:4.7KGS
|
Model
|
CRD-300
|
CRD-500
|
CRD-1000
|
CRD-1500
|
CRD-2000
|
CRD-3000
|
CRD-4000
|
CRD-5000
|
CRD-6000
|
||||||||
|
Continuous Power
|
300
|
500
|
1000
|
1500
|
2000
|
3000
|
4000
|
5000
|
6000
|
||||||||
|
Peaking Power
|
600
|
1000
|
2000
|
3000
|
4000
|
6000
|
8000
|
10000
|
12000
|
||||||||
|
Output Voltage (AC)
|
100/110/120/220/230/240VAC
|
||||||||||||||||
|
Input voltage (DC)
|
12V/24V/48VDC (Other voltage also can be customzied)
|
||||||||||||||||
|
Input Voltage RANGE
|
10-15VDC for 12V, 20-30VDC for 24V, 40-60VDC for 48V
|
||||||||||||||||
|
Bat.Low Voltage Alarm
|
11±0.5VDC for 12V, 22±1VDC for 24V, 44±2VDC for 48V
|
||||||||||||||||
|
Bat.Low Voltage Shut Down
|
10±0.5VDC for 12V, 20±1VDC, 40±2VDC
|
||||||||||||||||
|
Over Load
|
Shut down output voltage, recover automatically after removing overload
|
||||||||||||||||
|
Over Voltage
|
15±0.5VDC for 12V, 30±1VDC for 24V, 60±2VDC for 48V
|
||||||||||||||||
|
Over Temperature
|
Shut down output voltage, recover automatically after temperature goes down
|
||||||||||||||||
|
Short Circuit
|
Shut down output voltage, recover automatically after removing short circuit
|
||||||||||||||||
|
Bat.Reverse Polarity
|
1. From 300W to 500W, when the inverter is connected reversely, the inverter will not work, just reconnect the battery wires.
2. From 1000w to 6000w, when the inveter is connected reversely, the fuse will be burnt , the DC input will not work. You have to replace all burn fuses. |
||||||||||||||||
|
Reset Voltage after LVS
|
10.5±0.5VDC for 12V, 21±1VDC for 24V, 42±2VDC for 48V
|
||||||||||||||||
|
OLED Display
|
Input Voltage, Output Voltage, Power , Temperature, Working Status and Fault Prompt by Detail Words.
|
||||||||||||||||
|
Dimension(L*W*Hmm)
|
150*104*60
|
211*104*60
|
230*153*70
|
280*154*70
|
350*154*70
|
410*165*70
|
480*165*70
|
360*165*140
|
360*165*140
|
||||||||
Features：
Provides 6 kinds of intelligent protection which can protect your electrical equipment considerately. 1. Over Load Protection: When connected load exceeds the inverter rated power watts (W), the inverter will automatically shut down to stop the output. 2. Over Heat Protection: As the internal temperature of the inverter or the ambient temperature is too high, the inverter output will automatically stop to ensure the safety of electrical equipment. 3. High-Voltage Protection: When the DC input voltage exceeds the normal range of the inverter will automatically shut down to stop the output voltage is too high note when there may be damage to the machine. 4. Low-Voltage Protection: When the battery or power supply voltage is too low, the inverter will stop output automatic shutdown protection to protect the battery or power supply is not compromised. 5. Reverse Protection: When the inverter link reverse to battery, inverter fuse will be blown, without damaging the product itself, you need to replace the fuse.（A reverse protection circuit no burning fuse for 300w, 500w) 6. Short Circuit Protection: When the load is connected severe short-circuit fault, the inverter will automatically shut down to stop the output
